Rd 10mm
Product characteristics:
| Specification | BR-ISG-100 | |
| Nominal discharge current (8/20μs) | In | 100kA |
| Lightning impulse current (10/350μs) | Iimp | 100kA |
| 100% Lightning impulse sparkover voltage | Uas | ≤1.5kV |
| Rated power frequency withstand voltage | ≤250V | |
| Operating temperature range | ϑ | -40°C~+80°C |
| Length of enclosure | L | 130mm |
| Diameter of enclosure | D | 39mm |
| Enclosure material | Thermoplastic, UL94-V0 | |
| Connection | Rd 10mm | |
| Material (connection) | Steel | |
| Protection level | IP67 |
Features:
Isolating spark gap for indirect equipotential bonding
Protection of insulating flanges in pipelines
Accessories for lightning current absorbing connection
Utilizes robust spark gap technology to equalize the potential between the high and low voltage sides of AC services or to equalize the potential across insulated areas such as insulated pipeline flanges.
The isolating spark gap ensures lightning protection equipotential bonding and safely discharges overvoltages.
Maximum protection with the highest possible lightning current carrying capacity class H.
Durable in extreme conditions due to excellent corrosion resistance.
In the event of an overvoltage, the isolating spark gap becomes low impedance and discharges the voltage. Lightning protection equipotential bonding is thus ensured.
Application:
For indirect connection/grounding of operationally isolated system parts in the event of lightning.
Avoid failures, downtimes, and even leaks on pipelines and protect sensitive insulating flanges against sparkover.
