Karakteristik produk:
| Spesifikasi | BRRL-SC-VG | BRRL-SC-NG | BRRL-SC-TT | |
| Klasifikasi SPD menurut EN61643-11 | Type 2 + Type 3 | Type 2 + Type 3 | Type 2 + Type 3 | |
| Klasifikasi SPD menurut IEC61643-11 | Class II + Class III | Class II + Class III | Class II + Class III | |
| Nominal a.c. voltage | Tidak | 230V | 230V | 230V |
| Maks. operasi terus menerus a.c. voltase | Uc | 275V | 275V | 275V |
| Frequency | 50-60Hz | 50-60Hz | 50-60Hz | |
| Norminal discharge current (8/20μs) | Di dalam | 5kA | 5kA | 5kA |
| Maximum discharge current (8/20μs) | maksimal | 20kA | 20kA | 20kA |
| Nominal current | IL | 15A | 15A | 15A |
| Tingkat perlindungan tegangan | Ke atas | ≤1.3kV | ≤1.3kV | ≤1.3kV |
| Combined impulse | Uoc | 10KV | 10KV | 10KV |
| Waktu respons | ta | ≤100ns | ≤100ns | ≤100ns |
| Kisaran suhu pengoperasian | kamu | -40℃-80℃ | -40℃-80℃ | -40℃-80℃ |
| Operating state / fault indication | green light on: OK; green light off: replace | |||
| Bahan penutup | Termoplastik UL94-V0 | |||
| Tingkat perlindungan | IP65 | IP65 | IP65 | |
| Order code | B6014 | B6015 | B6016 | |
Fitur:
Up to IP65 rated enclosure for wet locations, high temperature / flameproof enclosure (80°C max surface rating).
Belongs to Class II+III SPD
Available in series use
The max. discharge current is 20kA/line.
Having a very low protection level of below 1.3Kv
LED status indicator
This arrestor fulfills the requirements for type 2+3 protective devices according to the current EN 61643-11 product norm.
Small construction size
Aplikasi:
Protect vulnerable equipment against the adverse effects produced by voltage spikes.
Protect LED lighting and the LED driver.
Suitable for LED Lighting, Roadway lighting, Traffic lighting, Digital signage, Wash wall lighting, Parking garage/lot lighting, Flood lighting, Tunnel lighting, Street lighting etc.
The surge protection device is also suitable for the protection of very sensitive components.
Notice:
After installing, the cable shall not be placed under direct sunlight to avoid expediting aging of the insulating
